YZH Stationary Rock Breaker System for Crushing Plants

YZH stationary rock breaker system is a machine designed to break large rocks.
Availability:
Quantity:
  • WHC860

  • YZH

YZH Stationary Rock Breaker System for Crushing Plants


YZH stationary rock breaker system is a machine we specially design for breaking. It can be generally used for grizzly, crusher or feed bin. In open pit or underground mines and quarries, aggregate plants, cement plants and steelworks where breaking is required, this equipment is suitable.


YZH stationary rock breaker system consists of pedestal boom, hydraulic hammer, hydraulic station and control system. It can be equipped with any manufacturers' hydraulic hammers. You can choose 2in1 radio remote control, electric cabin control and 5G teleoperation system. This equipment can be installed on anywhere possible. With more than 20 years of experience and professional R&D team, we will provide professional technical support. YZH stationary rock breaker system is with no emission, which is environmental friendly and energy-saving. It will bring great benefit to your work site.


Specification:

Model No. Unit WHC860
Max. horizontal working radius mm 11000
Max. vertical working radius mm 8665
Min. vertical working radius mm 3000
Max. working depth mm 7740
Rotation ° 360

pedestal boomboom system
