YZH Electric-powered Rockbreaker Boom System of 170° Rotation

YZH rockbreaker boom system is designed to operate in mines or quarries where breaking is required for oversize rocks.
Availability:
Quantity:
  • BC450

  • YZH

YZH Electric-powered Rockbreaker Boom System of 170° Rotation


YZH rockbreaker boom system is a machine designed to manage blockages and clear build ups in the crusher cavity. The core components of yzh rockbreaker boom system include pedestal boom, hydraulic hammer, hydraulic pressure station and control system. The power to weight ratio of the YZH range of hydraulic hammers provides superior efficiency and performance. The hydraulic pressure station enables the rockbreaker boom system to achieve the best energy efficiency and economy performance ratio. With 2in1 radio remote control, cabin control system and 5G optical fiber teleoperation system, it becomes convenient for you to operate.


Specification:

Model No. Unit BC450
Max. horizontal working radius mm 7400

Max. vertical working radius

mm 5300
Min. vertical working radius mm 2510
Max. working depth mm 4430
Rotation ° 170

We will manufacture and customize the rockbreaker boom system according to your needs.
