Pedestal Rockbreaker Boom

Pedestal rockbreaker boom is a machine designed to manipulate large rocks, including reducing large rocks into smaller rocks.
Availability:
Quantity:
  • WHC860

  • YZH

Pedestal Rockbreaker Boom

Pedestal rockbreaker boom consists of pedestal boom, hydraulic hammer, hydraulic power unit and operating control. It can quickly eliminate crusher blocks and provide smooth material flow. It will increase in work productivity by reducing the downtime of the crusher.


Pedestal rockbreaker boom is equipped with electric motor drive and remote control, which makes it convenient and reduces the cost. The suitable location of equipment enables you to reach the crusher and hopper at the same time. We provide customized solution and optional equipment.

Model No. WHC860
Max. Horizontal working radius(R1) 11000mm
Max. Vertical working radius(R2) 8665mm
Min. Vertical working radius(R3) 3000mm
Max. working depth(H2) 7740mm
Rotation 360°

rockbreaker booms systemsrockbreaker booms systemrockbreaker booms
