Hydraulic Pedestal Boom Rockbreaker System

YZH is one of the pioneer manufacturer of Stationary Boom Breaker System in China. These Pedestal Boom Breaker system is suitable for underground mining, stationary crusher application and mobile crusher application.
Availability:
Quantity:
  • Series L

  • YZH

  • YZH-L850

YZH-L850 Hydraulic Pedestal Boom Rockbreaker Systems

This product is possible to equip to your Jaw-Crusher on Main Body or on any nearby parts of the unit and easy to operate by a beginner.


This product is possible to equip to your Jaw-Crusher on Main Body or on any nearby parts of the unit and easy to operate a beginner.This will prevent your high valued equipment to be damaged or safety accident caused by overload on your Jaw-Crusher through smashing the original stones sitting on the inlet open ing of Jaw-Crusher while operating.


Characters Of  The Stationary Pedestal Boom Breaker

1. Productivity improvement

2. Simple operation / Minimized the manual operation

3. Breaking blocked oversize material quickly and safely

4. Solving bridging problems by raking material into the crusher


Unit

YZH-L850

Weight

Kg

7700

Maximum Reach

m

10.6

Nominal Horizontal Reach (H)

m

8.3

Nominal Vertical Reach (V)

m

6.9

Swing°

°

170

Base Diameter

m

1.86

Recommended Hydraulic Hammer (Chisel   Size)

mm

135, 140

Recommended Power Packs


HA 37, HA 45

booms systemHydraulic Manipulator ArmRockbreaker Booms
