China Pedestal Static Type Rockbreaker Boom System
The China pedestal static type rockbreaker boom system is mainly used to reduce oversized boulders, rake all rock materials into the crusher, and can extend into the crusher mouth or hopper to assist in handling and cleaning blockages.
China pedestal static type rockbreaker boom system
The China pedestal static type rockbreaker boom system is mainly used to reduce oversized boulders, rake all rock materials into the crusher, and can extend into the crusher mouth or hopper to assist in handling and cleaning blockages. These China pedestal static type rockbreaker boom systems provide the widest range of boom and crusher sizes in the industry, and in summary, the China pedestal static type rockbreaker boom system is a simple, cost-effective, and safe crushing solution. The China pedestal static type rockbreaker boom system is mainly designed for the mining market and can also be used for various working conditions of different types.
In the sand and gravel industry, China pedestal static type rockbreaker boom systems are mainly used for fixed jaw crushers, rotary crushers, and mobile crushing stations. Due to the feeding port of the crusher, the size of the material is prone to jamming, which affects the subsequent feeding speed and poses safety risks to production; At the feeding port of the jaw crusher, if multiple large pieces of material are simultaneously entered, it is easy to cause overload protection shutdown of the China pedestal static type rockbreaker boom system, which affects the crushing efficiency; In addition, some materials have a smooth and rounded appearance without any edges, and the friction force is too small, making them prone to slipping when the jawbone is fractured and occluded. In addition, after the first blasting, the size of the ore blocks in the original rock cannot meet the limit size for loading or feeding, so a second blasting must be carried out. The second blasting brings great safety risks to production and can cause damage to the surrounding environment.
Model No
Unit
BB500
Boom weight (without hammer)
kg
3396
Max. Horizontal working
mm
7400
Max.Vertical working radius
mm
5360
Min Vertical working radius
mm
2220
Rotation
°
170
China pedestal static type rockbreaker boom system
The China pedestal static type rockbreaker boom system is mainly used to reduce oversized boulders, rake all rock materials into the crusher, and can extend into the crusher mouth or hopper to assist in handling and cleaning blockages. These China pedestal static type rockbreaker boom systems provide the widest range of boom and crusher sizes in the industry, and in summary, the China pedestal static type rockbreaker boom system is a simple, cost-effective, and safe crushing solution. The China pedestal static type rockbreaker boom system is mainly designed for the mining market and can also be used for various working conditions of different types.
In the sand and gravel industry, China pedestal static type rockbreaker boom systems are mainly used for fixed jaw crushers, rotary crushers, and mobile crushing stations. Due to the feeding port of the crusher, the size of the material is prone to jamming, which affects the subsequent feeding speed and poses safety risks to production; At the feeding port of the jaw crusher, if multiple large pieces of material are simultaneously entered, it is easy to cause overload protection shutdown of the China pedestal static type rockbreaker boom system, which affects the crushing efficiency; In addition, some materials have a smooth and rounded appearance without any edges, and the friction force is too small, making them prone to slipping when the jawbone is fractured and occluded. In addition, after the first blasting, the size of the ore blocks in the original rock cannot meet the limit size for loading or feeding, so a second blasting must be carried out. The second blasting brings great safety risks to production and can cause damage to the surrounding environment.
